Features:
- Narrow body design for better clearance
- Maximum T.IR. of 0.0001" at 3X diameter
- AD/B CoolFLEX coolant delivery standard
Product Specifications
| Taper | CAT40 |
| Nose Diameter (mm) | 32mm |
| Body Diameter (mm) | 50mm |
| Overall Diameter (mm) | 44.45mm |
| Projection (mm) | 80.5mm |
| Nose Length (mm) | 32mm |
| Bore Depth (mm) | 37mm |
| Overall Length (mm) | 148.75mm |
