Features:
- Positive Radial Rake
- Variable Flute Pattern
- Open Center Design
- Long Reach
Product Specifications
| Manufacturer Part Number | 47747 |
| Cutting Diameter (Decimal Inch) | 0.787" |
| Cutting Diameter (mm) | 20.00mm |
| Shank Diameter (Decimal Inch) | 0.787" |
| Shank Diameter (mm) | 20.00mm |
| Length of Cut (Decimal Inch) | 1.693" |
| Length of Cut (mm) | 43.00mm |
| Overall Length (Decimal Inch) | 5.906" |
| Overall Length (mm) | 150.00mm |
| Reach (Decimal Inch) | 3.150" |
| Reach (mm) | 80.00mm |
| Neck Diameter (Decimal Inch) | 0.748" |
| Neck Diameter (mm) | 19.00mm |
| Corner Radius (Decimal Inch) | 0.059" |
| Corner Radius (mm) | 1.50mm |
| Shank Diameter Tolerance | h6 |
| Flute Type | Spiral |
| Number of Flutes | 5 |
| Center Cutting | No |
| Chip Breaker | Yes |
| High Performance | Yes |
| Coating | TM (Ti-NAMITE-M) |
| Product Type | Chip Breaker Corner Radius End Mill |
