Product Specifications
| Manufacturer Part Number | 74016015 |
| Inscribed Circle Diameter (Decimal Inch) | 0.375" |
| Inscribed Circle Diameter (mm) | 9.53mm |
| Corner Radius (Decimal Inch) | 0.047" |
| Corner Radius (mm) | 1.20mm |
| Wiper Edge Length (Decimal Inch) | 0.039" |
| Wiper Edge Length (mm) | 1.00mm |
| Theoretical Cutting Edge Length (Decimal Inch) | 0.630" |
| Theoretical Cutting Edge Length (mm) | 16.00mm |
| Insert Thickness (Decimal Inch) | 0.125" |
| Insert Thickness (mm) | 3.18mm |
| Clearance Angle Major (Degree) | 11 Degree |
| Cutting Edge Count | 3 |
| Cutting Geometry Type | MD |
| Cutting Geometry Type Technical | MD12 |
| Insert Included Angle (Degree) | 60 Degree |
| Material | Carbide |
| Insert Hand | Right Hand |
| Product Type | Milling Insert |
