Product Specifications
| Manufacturer Part Number | 17004719 |
| Maximum Depth of cut in Feed Direction Side (Decimal Inch) | 1.250" |
| Chamfer Width (Decimal Inch) | 0.025" |
| Cutting Diameter (Decimal Inch) | 0.500" |
| Shank Diameter (Decimal Inch) | 0.500" |
| Overall Length (Decimal Inch) | 3.000" |
| Shank Diameter Tolerance Class | ANSI B94.19 |
| Series | AR330 |
| Number of Flutes | 3 |
| Pheripheral Cutting Edge Count | 3 |
| Shank Type | Cylindrical |
| Center Cutting | Yes |
| Helix Angle (Degree) | 30 Degree |
| Corner Chamfer Angle (Degree) | 45 Degree |
| Coating | TiCN |
| Product Type | Corner Chamfer End Mill |
