Product Specifications
| Manufacturer Part Number | 10341828 |
| Fixing Hole Diameter (Decimal Inch) | 0.114" |
| Inscribed Circle Diameter (Decimal Inch) | 0.250" |
| Cutting Edge Length (Decimal Inch) | 0.254" |
| Cutting Edge Effective Length (Decimal Inch) | 0.246" |
| Corner Radius (Decimal Inch) | 0.008" |
| Insert Thickness (Decimal Inch) | 0.094" |
| Cutting Edge Count | 2 |
| Chip Breaker Manufacturers Designation | F1 |
| Grade | TS2050 |
| Grade type | Carbide PVD |
| Insert Seat Size Code | 06 |
| Insert Hand | Neutral |
| Insert Included Angle (Degree) | 80 Degree |
| Clearance Angle (Degree) | 7 Degree |
| Coating | PVD |
| Material | Carbide |
| Product Type | Turning Insert |
