Product Specifications
| Manufacturer Part Number | 10327222 |
| Nose Diameter (Decimal Inch) | 0.984" |
| Minimum Connection Bore Diameter (Decimal Inch) | 0.236" |
| Maximum Connection Bore Diameter (Decimal Inch) | 0.236" |
| Body Length (Decimal Inch) | 1.063" |
| Secondary Functional length (Decimal Inch) | 1.260" |
| Protruding Length (Decimal Inch) | 1.969" |
| Clamping Length (Decimal Inch) | 1.063" |
| Overall Length (Decimal Inch) | 3.150" |
| Machine Side Connection Text | C5 |
| Complete Insert Compatibility | EM06 |
| Balance Quality Code | Pre-Balanced |
| Data Chip Pocket | Yes |
| Product Type | End Mill Holder |
