Product Specifications
| Manufacturer Part Number | 10325106 |
| Wiper Edge Length (Decimal Inch) | 0.059" |
| Inscribed Circle Diameter (Decimal Inch) | 0.622" |
| Cutting Edge Effective Length (Decimal Inch) | 0.177" |
| Corner Radius (Decimal Inch) | 0.024" |
| Insert Thickness (Decimal Inch) | 0.219" |
| Insert Size and Shape | OOET0605v |
| Cutting Edge Count | 8 |
| Cutting Geometry Type Technical | D20 |
| Grade | MH1051 |
| Grade type | Carbide PVD |
| Insert Hand | Neutral |
| Clearance Angle (Degree) | 18 Degree |
| Coating | PVD |
| Material | Carbide |
| Product Type | Milling Insert |
