Product Specifications
| Manufacturer Part Number | 10198787 |
| Fixing Hole Diameter (mm) | 3.00mm |
| Corner Radius (mm) | 3.10mm |
| Cutting Edge Effective Length (mm) | 9.30mm |
| Wiper Edge Length (mm) | 0.40mm |
| Insert Thickness (mm) | 3.83mm |
| Insert Width (mm) | 6.90mm |
| Clearance Angle Major (Degree) | 15 Degree |
| Cutting Edge Count | 2 |
| Cutting Geometry Type | M |
| Cutting Geometry Type Technical | M09 |
| Insert Size And Shape | XOMX10T3 |
| Insert Rake Angle (Degree) | 10.6 Degree |
| Material | Carbide |
| Insert Hand | Right Hand |
| Product Type | Milling Insert |
