Product Specifications
| Manufacturer Part Number | 10198690 |
| Inscribed Circle Diameter (mm) | 8.00mm |
| Insert Diameter (mm) | 8.00mm |
| Fixing Hole Diameter (mm) | 2.90mm |
| Corner Radius (mm) | 4.00mm |
| Insert Thickness (mm) | 3.18mm |
| Clearance Angle Major (Degree) | 15 Degree |
| Cutting Edge Count | 4 |
| Cutting Geometry Type | E |
| Cutting Geometry Type Technical | E03 |
| Insert Size And Shape | RDHT0803 |
| Insert Rake Angle (Degree) | 20 Degree |
| Material | Carbide |
| Insert Hand | Neutral |
| Insert Shape Code | R |
| Product Type | Milling Insert |
