Product Specifications
| Manufacturer Part Number | 10198689 |
| Fixing Hole Diameter (mm) | 4.50mm |
| Cutting Edge Effective Length (mm) | 14.00mm |
| Insert Length (mm) | 14.00mm |
| Curved Cutting Edge Radius (mm) | 9.75mm |
| Corner Radius (mm) | 2.00mm |
| Insert Thickness (mm) | 4.76mm |
| Cutting Edge Count | 2 |
| Clearance Angle Major (Degree) | 11 Degree |
| Insert Rake Angle (Degree) | 10 Degree |
| Insert Hand | Right Hand |
| Cutting Geometry Type | M |
| Cutting Geometry Type Technical | M13 |
| Pocket Seat Code of The Cutter | LP..09T4 |
| Insert Size And Shape | LPKT09T4 |
| Insert Shape Code | L |
| Material | Carbide |
| Product Type | Milling Insert |
