Product Specifications
| Manufacturer Part Number | 10139426 |
| Thread Diameter (Decimal Inch) | 0.831" |
| Thread Diameter (mm) | 21.11mm |
| Threading Chamfer Length (Decimal Inch) | 0.311" |
| Threading Chamfer Length (mm) | 7.90mm |
| Tap Chamfer Length (Decimal Inch) | 0.311" |
| Tap Chamfer Length (mm) | 7.90mm |
| Connection Diameter Machine Side (Decimal Inch) | 0.630" |
| Connection Diameter Machine Side (mm) | 16.00mm |
| Shank Diameter (Decimal Inch) | 0.630" |
| Shank Diameter (mm) | 16.00mm |
| Functional Length (Decimal Inch) | 4.610" |
| Functional Length (mm) | 117.10mm |
| Usable Length (Decimal Inch) | 3.150" |
| Usable Length (mm) | 80.00mm |
| Overall Length (Decimal Inch) | 4.921" |
| Overall Length (mm) | 125.00mm |
| Thread Length (Decimal Inch) | 0.669" |
| Thread Length (mm) | 17.00mm |
| Thread Diameter Size | EGUNF3/4-16 |
| Recommended Premachined Hole Diameter (Decimal Inch) | 0.768" |
| Recommended Premachined Hole Diameter (mm) | 19.50mm |
| Connection Size Code | 16.00X12.00 |
| Connection Size Code Machine Side | 16.00X12.00 |
| Maximum Premachined Hole Diameter (Decimal Inch) | 0.772" |
| Maximum Premachined Hole Diameter (mm) | 19.61mm |
| Minimum Threads Per Inch (mm) | 16.00mm |
| Maximum Threads Per Inch (mm) | 16.00mm |
| Number of Flute | 4 |
| Shank Type | Cylindrical |
| Thread Tolerance Class | 2B |
| Threading Chamfer Type | B |
| Thread Form Type | EGUNF |
| Cutting Direction | Right Hand |
| Cutting Geometry Type | T34 |
| Cutting Geometry Type Technical | Straight with spiral point |
| Material | HSS-E-PM |
| Coating | TiAIN+WC/C |
| Product Type | Straight Flute Tap |
