Product Specifications
| Manufacturer Part Number | 10137145 |
| Connection Bore Diameter (Decimal Inch) | 1.260" |
| Connection Bore Diameter (mm) | 32.00mm |
| Minimum Connection Bore Diameter (Decimal Inch) | 1.260" |
| Minimum Connection Bore Diameter (mm) | 32.00mm |
| Maximum Connection Bore Diameter (Decimal Inch) | 1.260" |
| Maximum Connection Bore Diameter (mm) | 32.00mm |
| Body Diameter 1 (Decimal Inch) | 2.835" |
| Body Diameter 1 (mm) | 72.00mm |
| Thread Diameter Size | M8x1 |
| Connection Bore Depth (Decimal Inch) | 0 |
| Connection Bore Depth (mm) | 62.50mm |
| Body Length (Decimal Inch) | 2.047" |
| Body Length (mm) | 52.00mm |
| Functional Length (Decimal Inch) | 1.535" |
| Functional Length (mm) | 39.00mm |
| Minimum Functional Length (Decimal Inch) | 1.142" |
| Minimum Functional Length (mm) | 29.00mm |
| Protruding Length (Decimal Inch) | 3.543" |
| Protruding Length (mm) | 90.00mm |
| Overall Length (Decimal Inch) | 7.551" |
| Overall Length (mm) | 191.80mm |
| Machine Side Group | BT & BT Taper-face |
| Product Type | Hydraulic Chuck |
