Product Specifications
| Manufacturer Part Number | 10137143 |
| Connection Bore Diameter (Decimal Inch) | 0.787" |
| Connection Bore Diameter (mm) | 20.00mm |
| Minimum Connection Bore Diameter (Decimal Inch) | 0.787" |
| Minimum Connection Bore Diameter (mm) | 20.00mm |
| Maximum Connection Bore Diameter (Decimal Inch) | 0.787" |
| Maximum Connection Bore Diameter (mm) | 20.00mm |
| Body Diameter 1 (Decimal Inch) | 1.939" |
| Body Diameter 1 (mm) | 49.25mm |
| Thread Diameter Size | M8x1 |
| Connection Bore Depth (Decimal Inch) | 0 |
| Connection Bore Depth (mm) | 52.50mm |
| Body Length (Decimal Inch) | 1.791" |
| Body Length (mm) | 45.50mm |
| Functional Length (Decimal Inch) | 1.240" |
| Functional Length (mm) | 31.50mm |
| Minimum Functional Length (Decimal Inch) | 0.847" |
| Minimum Functional Length (mm) | 21.50mm |
| Protruding Length (Decimal Inch) | 2.854" |
| Protruding Length (mm) | 72.50mm |
| Overall Length (Decimal Inch) | 5.429" |
| Overall Length (mm) | 137.90mm |
| Machine Side Group | BT & BT Taper-face |
| Product Type | Hydraulic Chuck |
