Product Specifications
| Manufacturer Part Number | 10106106 |
| Cutting Diameter (mm) | 10.00mm |
| Connection Diameter Machine Side (mm) | 10.00mm |
| Shank Diameter (mm) | 10.00mm |
| Overall Length (mm) | 89.00mm |
| Cutting Edge Effective Length (mm) | 12.30mm |
| Maximum Depth of Cut (mm) | 12.30mm |
| Shank Type | Cylindrical |
| Center Cutting Capability | Yes |
| Cutting Edge Count | 4 |
| Cutting Geometry Type | JH724 |
| Cutting Geometry Type Technical | JH724 |
| Face Cutting Edge Count | 4 |
| Flute Helix Angle (Degree) | 38 Degree |
| Flute Helix Direction | Right |
| Rake Radial Angle (Degree) | 10 Degree |
| Axial Rake Angle (Degree) | 10 Degree |
| Cutting Direction | Right Hand |
| Internal Coolant Channel | No |
| Number of Flute | 4 |
| Material | Carbide |
| Coating | HXT |
| Product Type | Tapered End Mill |
