Product Specifications
| Manufacturer Part Number | 10071303 |
| Fixing Hole Diameter (Decimal Inch) | 0.305" |
| Fixing Hole Diameter (mm) | 7.75mm |
| Inscribed Circle Diameter (Decimal Inch) | 0.750" |
| Inscribed Circle Diameter (mm) | 19.05mm |
| Cutting Edge Effective Length (Decimal Inch) | 0.593" |
| Cutting Edge Effective Length (mm) | 15.05mm |
| Theoretical Cutting Edge Length (Decimal Inch) | 0.760" |
| Theoretical Cutting Edge Length (mm) | 19.30mm |
| Corner Radius (Decimal Inch) | 0.158" |
| Corner Radius (mm) | 4.00mm |
| Insert Thickness (Decimal Inch) | 0.433" |
| Insert Thickness (mm) | 11.00mm |
| Cutting Edge Count | 8 |
| Insert Included Angle (Degree) | 90 Degree |
| Insert Hand | Neutral |
| Insert Size And Shape | SN1911 |
| Insert Shape Code | S |
| Material | Carbide |
| Product Type | Turning Insert |
