Product Specifications
| Manufacturer Part Number | 03305480 |
| Thread Diameter (Decimal Inch) | 0.250" |
| Thread Diameter (mm) | 6.35mm |
| Threading Chamfer Length (Decimal Inch) | 0.137" |
| Threading Chamfer Length (mm) | 3.49mm |
| Tap Chamfer Length (Decimal Inch) | 0.137" |
| Tap Chamfer Length (mm) | 3.49mm |
| Connection Diameter Machine Side (Decimal Inch) | 0.276" |
| Connection Diameter Machine Side (mm) | 7.00mm |
| Shank Diameter (Decimal Inch) | 0.276" |
| Shank Diameter (mm) | 7.00mm |
| Functional Length (Decimal Inch) | 3.012" |
| Functional Length (mm) | 76.50mm |
| Usable Length (Decimal Inch) | 0.984" |
| Usable Length (mm) | 25.00mm |
| Overall Length (Decimal Inch) | 3.150" |
| Overall Length (mm) | 80.00mm |
| Thread Length (Decimal Inch) | 0.614" |
| Thread Length (mm) | 15.60mm |
| Thread Diameter Size | UNC1/4-20 |
| Recommended Premachined Hole Diameter (Decimal Inch) | 0.201" |
| Recommended Premachined Hole Diameter (mm) | 5.10mm |
| Connection Size Code | 8.25X5.5 |
| Connection Size Code Machine Side | 8.25X5.5 |
| Maximum Premachined Hole Diameter (Decimal Inch) | 0.207" |
| Maximum Premachined Hole Diameter (mm) | 5.27mm |
| Minimum Threads Per Inch (mm) | 20.00mm |
| Maximum Threads Per Inch (mm) | 20.00mm |
| Number of Flute | 5 |
| Shank Type | Cylindrical |
| Thread Tolerance Class | 2BX |
| Threading Chamfer Type | C |
| Thread Form Type | UNC |
| Cutting Direction | Right Hand |
| Cutting Geometry Type | ISO-K |
| Cutting Geometry Type Technical | Straight |
| Material | HSS-E-PM |
| Coating | TIALN |
| Product Type | Straight Flute Tap |
