Product Specifications
| Manufacturer Part Number | 03284736 |
| Coolant Supply Property | 1 |
| Coolant Exit Style Code | 10 |
| Cutting Diameter Internal Minimum (Decimal Inch) | 9.843" |
| Cutting Diameter Internal Minimum 3 (Decimal Inch) | 4.331" |
| Cutting Direction | Right Hand |
| Functional Height (Decimal Inch) | 0.750" |
| Functional Length (Decimal Inch) | 1.654" |
| Head Length (Decimal Inch) | 1.811" |
| Shank Length (Decimal Inch) | 2.362" |
| Overall Length (Decimal Inch) | 4.173" |
| Shank Type | Square shank |
| Insert seat size code | 1204 |
| Version (Internal/External/Both) | External |
| Functional Width (Decimal Inch) | 1.059" |
| Product Series | DCLC |
| Product Type | Indexable Boring Bar |
