Product Specifications
| Manufacturer Part Number | 03277877 |
| Cutting Diameter (Decimal Inch) | 2.000" |
| Cutting Diameter (mm) | 50.80mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 0.906" |
| Contact Surface Diameter Machine Side (mm) | 23.00mm |
| Body Diameter (Decimal Inch) | 0.728" |
| Body Diameter (mm) | 18.50mm |
| Body Length (Decimal Inch) | 0.405" |
| Body Length (mm) | 10.29mm |
| Functional Length (Decimal Inch) | 1.102" |
| Functional Length (mm) | 28.00mm |
| Cutting Width (Decimal Inch) | 0.156" |
| Cutting Width (mm) | 3.97mm |
| Maximum Depth of Cut (Decimal Inch) | 0.156" |
| Maximum Depth of Cut (mm) | 3.97mm |
| Maximum Cutting Depth (Decimal Inch) | 0.602" |
| Maximum Cutting Depth (mm) | 15.30mm |
| Connection Mounting Torque (Nm) | 60.0 Nm |
| Tool Cutting Edge Angle (Degree) | 90 Degree |
| Tool Cutting Edge Angle In Feed Direction End (Degree) | 90 Degree |
| Tool Cutting Edge Angle In Feed Direction Side (Degree) | 90 Degree |
| Rake Radial Angle (Degree) | -17 Degree |
| Cutting Direction | Right Hand |
| Maximum Rotational Speed (rpm) | 19100 rpm |
| Coolant Entry Style Code | 1 |
| Cutting Pitch Density | Close |
| Coolant Supply Property | 1 |
| Pocket Seat Code of The Cutter | 335.19-1102 |
| Coolant Exit Style Code | 2 |
| Cutting Item Material Type | Steel |
| Shank Type | Combimaster |
| Product Type | Indexable Slotting Cutter |
