Product Specifications
| Manufacturer Part Number | 03201473 |
| Body Diameter 1 (Decimal Inch) | 1.102" |
| Body Diameter 1 (mm) | 28.00mm |
| Body Diameter 2 (Decimal Inch) | 0.860" |
| Body Diameter 2 (mm) | 21.85mm |
| Minimum Connection Bore Diameter (Decimal Inch) | 0.020" |
| Minimum Connection Bore Diameter (mm) | 0.50mm |
| Maximum Connection Bore Diameter (Decimal Inch) | 0.394" |
| Maximum Connection Bore Diameter (mm) | 10.00mm |
| Body Length (Decimal Inch) | 1.250" |
| Body Length (mm) | 31.75mm |
| Functional Length (Decimal Inch) | 0.661" |
| Functional Length (mm) | 16.80mm |
| Protruding Length (Decimal Inch) | 2.000" |
| Protruding Length (mm) | 50.80mm |
| Overall Length (Decimal Inch) | 4.687" |
| Overall Length (mm) | 119.05mm |
| Data Chip Provision | 1 |
| Maximum Rotational Speed (rpm) | 18000 rpm |
| Product Type | Collet Chuck |
