Product Specifications
| Manufacturer Part Number | 03197155 |
| Body Diameter (Decimal Inch) | 4.874" |
| Body Diameter (mm) | 123.80mm |
| Connection Diameter Workpiece Side (Decimal Inch) | 2.500" |
| Connection Diameter Workpiece Side (mm) | 63.50mm |
| Shank Diameter (Decimal Inch) | 2.500" |
| Shank Diameter (mm) | 63.50mm |
| Body Length (Decimal Inch) | 1.650" |
| Body Length (mm) | 41.91mm |
| Functional Length (Decimal Inch) | 2.400" |
| Functional Length (mm) | 60.96mm |
| Clamping Length (Decimal Inch) | 1.125" |
| Clamping Length (mm) | 28.58mm |
| Overall Length (Decimal Inch) | 7.525" |
| Overall Length (mm) | 191.14mm |
| Data Chip Provision | 1 |
| Maximum Rotational Speed (rpm) | 12000 rpm |
| Product Type | Shell Mill Holder |
