Product Specifications
| Manufacturer Part Number | 03122643 |
| Inscribed Circle Diameter (Decimal Inch) | 0.472" |
| Inscribed Circle Diameter (mm) | 12.00mm |
| Cutting Edge Effective Length (Decimal Inch) | 0.441" |
| Cutting Edge Effective Length (mm) | 11.20mm |
| Corner Radius (Decimal Inch) | 0.032" |
| Corner Radius (mm) | 0.80mm |
| Insert Thickness (Decimal Inch) | 0.189" |
| Insert Thickness (mm) | 4.80mm |
| Cutting Edge Count | 8 |
| Cutting Geometry Type | MD |
| Cutting Geometry Type Technical | MD13 |
| Pocket Seat Code of The Cutter | SN.U1204 |
| Insert Size And Shape | SNMU1204 |
| Insert Hand | Neutral |
| Material | Carbide |
| Product Type | Milling Insert |
