Product Specifications
| Manufacturer Part Number | 02955765 |
| Fixing Hole Diameter (Decimal Inch) | 0.177" |
| Fixing Hole Diameter (mm) | 4.50mm |
| Inscribed Circle Diameter (Decimal Inch) | 0.500" |
| Inscribed Circle Diameter (mm) | 12.70mm |
| Insert Length (Decimal Inch) | 1.205" |
| Insert Length (mm) | 30.61mm |
| Corner Radius (Decimal Inch) | 0.630" |
| Corner Radius (mm) | 16.00mm |
| Insert Thickness (Decimal Inch) | 0.252" |
| Insert Thickness (mm) | 6.40mm |
| Cutting Edge Count | 2 |
| Clearance Angle Major (Degree) | 15 Degree |
| Insert Rake Angle (Degree) | 6 Degree |
| Insert Hand | Right Hand |
| Cutting Geometry Type | ME |
| Cutting Geometry Type Technical | ME08 |
| Pocket Seat Code of The Cutter | 218.20-160 |
| Insert Size And Shape | 218.20-160 |
| Insert Shape Code | 218.20 |
| Material | Carbide |
| Product Type | Milling Insert |
