Product Specifications
| Manufacturer Part Number | 02904949 |
| Fixing Hole Diameter (Decimal Inch) | 0.197" |
| Fixing Hole Diameter (mm) | 5.00mm |
| Inscribed Circle Diameter (Decimal Inch) | 0.472" |
| Inscribed Circle Diameter (mm) | 12.00mm |
| Wiper Edge Length (Decimal Inch) | 0.012" |
| Wiper Edge Length (mm) | 0.30mm |
| Cutting Edge Effective Length (Decimal Inch) | 0.142" |
| Cutting Edge Effective Length (mm) | 3.60mm |
| Corner Radius (Decimal Inch) | 0.039" |
| Corner Radius (mm) | 1.00mm |
| Insert Thickness (Decimal Inch) | 0.174" |
| Insert Thickness (mm) | 4.43mm |
| Cutting Edge Condition Code | S |
| Cutting Edge Count | 8 |
| Cutting Geometry Type Technical | LF |
| Pocket Seat Code of The Cutter | ON.U0504 |
| Insert Size And Shape | ONEW0504 |
| Material | PCBN |
| Product Type | Milling Insert |
