Product Specifications
| Manufacturer Part Number | 02902989 |
| Insert Diameter (Decimal Inch) | 0.047" |
| Insert Diameter (mm) | 1.20mm |
| Insert Gauge Length (Decimal Inch) | 0.747" |
| Insert Gauge Length (mm) | 18.97mm |
| Insert Length (Decimal Inch) | 0.996" |
| Insert Length (mm) | 25.29mm |
| Cutting Width (Decimal Inch) | 0.047" |
| Cutting Width (mm) | 1.20mm |
| Maximum Cutting Depth Insert (Decimal Inch) | 0.169" |
| Maximum Cutting Depth Insert (mm) | 4.30mm |
| Corner Radius (Decimal Inch) | 0.024" |
| Corner Radius (mm) | 0.60mm |
| Insert Thickness (Decimal Inch) | 0.802" |
| Insert Thickness (mm) | 20.37mm |
| Cutting Edge Count | 4 |
| Clearance Angle Major (Degree) | 6 Degree |
| Insert Hand | Right Hand |
| Insert Size And Shape | X42503R |
| Material | Carbide |
| Product Type | Grooving Insert |
