Product Specifications
| Manufacturer Part Number | 02899111 |
| Cutting Diameter (mm) | 13.60mm |
| Connection Diameter Machine Side (mm) | 14.00mm |
| Shank Diameter (mm) | 14.00mm |
| Chip Flute Length (mm) | 60.00mm |
| Functional Length Secondary (mm) | 62.00mm |
| Shank Length (mm) | 45.00mm |
| Usable Length (mm) | 43.00mm |
| Overall Length (mm) | 107.00mm |
| Point Length (mm) | 2.48mm |
| Tool Cutting Edge Angle (Degree) | 70 Degree |
| Flute Helix Angle (Degree) | 30 Degree |
| Flute Helix Hand | Right Hand |
| Shank Type | Cylindrical |
| Material | Carbide |
| Product Type | Screw Machine Length Drill Bit |
