Product Specifications
| Manufacturer Part Number | 02808735 |
| Insert Length (Decimal Inch) | 0.559" |
| Insert Length (mm) | 14.20mm |
| Cutting Edge Effective Length (Decimal Inch) | 0.516" |
| Cutting Edge Effective Length (mm) | 13.10mm |
| Insert Width (Decimal Inch) | 0.272" |
| Insert Width (mm) | 6.90mm |
| Corner Radius (Decimal Inch) | 0.158" |
| Corner Radius (mm) | 4.00mm |
| Cutting Edge Count | 4 |
| Cutting Geometry Type Technical | M11 |
| Insert Size And Shape | XNHQ1407 |
| Insert Rake Angle (Degree) | 16 Degree |
| Insert Hand | Neutral |
| Material | Carbide |
| Product Type | Disc Milling Insert |
