Product Specifications
| Manufacturer Part Number | 02732338 |
| Cutting Diameter (mm) | 25.00mm |
| Contact Surface Diameter Machine Side (mm) | 23.00mm |
| Thread Diameter Size | M12 |
| Functional Length (mm) | 30.00mm |
| Maximum Depth of Cut (mm) | 7.00mm |
| Connection Mounting Torque (Nm) | 60.0 Nm |
| Rake Radial Angle (Degree) | -7 Degree |
| Rake Radial Angle (Degree) | -7 Degree |
| Axial Rake Angle (Degree) | 5 Degree |
| Tool Cutting Edge Angle (Degree) | 98 Degree |
| Tool Cutting Edge Angle In Feed Direction End (Degree) | 98 Degree |
| Tool Cutting Edge Angle In Feed Direction Side (Degree) | 90 Degree |
| Maximum Rotational Speed (rpm) | 20800 rpm |
| Shank Type | Combimaster |
| Product Type | Plunge Mill |
