Product Specifications
| Manufacturer Part Number | 02732333 |
| Cutting Diameter (mm) | 32.00mm |
| Connection Diameter Machine Side (mm) | 25.00mm |
| Shank Diameter (mm) | 25.00mm |
| Protruding Length (mm) | 194.00mm |
| Shank Length (mm) | 215.00mm |
| Overall Length (mm) | 250.00mm |
| Maximum Depth of Cut (mm) | 7.00mm |
| Rake Radial Angle (Degree) | -7 Degree |
| Rake Radial Angle (Degree) | -7 Degree |
| Axial Rake Angle (Degree) | 5 Degree |
| Tool Cutting Edge Angle (Degree) | 98 Degree |
| Tool Cutting Edge Angle In Feed Direction End (Degree) | 98 Degree |
| Tool Cutting Edge Angle In Feed Direction Side (Degree) | 90 Degree |
| Maximum Rotational Speed (rpm) | 18400 rpm |
| Shank Type | Cylindrical |
| Product Type | Plunge Mill |
