Product Specifications
| Manufacturer Part Number | 02616001 |
| Fixing Hole Diameter (Decimal Inch) | 0.203" |
| Fixing Hole Diameter (mm) | 5.15mm |
| Inscribed Circle Diameter (Decimal Inch) | 0.500" |
| Inscribed Circle Diameter (mm) | 12.70mm |
| Cutting Edge Effective Length (Decimal Inch) | 0.579" |
| Cutting Edge Effective Length (mm) | 14.70mm |
| Cutting Width (Decimal Inch) | 0.039" |
| Cutting Width (mm) | 1.00mm |
| Functional Width (Decimal Inch) | 0.116" |
| Functional Width (mm) | 2.95mm |
| Corner Radius (Decimal Inch) | 0.032" |
| Corner Radius (mm) | 0.80mm |
| Insert Thickness (Decimal Inch) | 0.187" |
| Insert Thickness (mm) | 4.76mm |
| Cutting Edge Count | 4 |
| Insert Size And Shape | DN1504 |
| Insert Included Angle (Degree) | 55 Degree |
| Insert Hand | Neutral |
| Material | Carbide |
| Product Type | Turning Insert |
