Product Specifications
| Manufacturer Part Number | 02610394 |
| Body Diameter (Decimal Inch) | 3.500" |
| Body Diameter (mm) | 88.90mm |
| Connection Diameter Workpiece Side (Decimal Inch) | 1.500" |
| Connection Diameter Workpiece Side (mm) | 38.10mm |
| Shank Diameter (Decimal Inch) | 1.500" |
| Shank Diameter (mm) | 38.10mm |
| Body Length (Decimal Inch) | 0.701" |
| Body Length (mm) | 17.80mm |
| Functional Length (Decimal Inch) | 2.000" |
| Functional Length (mm) | 50.80mm |
| Clamping Length (Decimal Inch) | 0.941" |
| Clamping Length (mm) | 23.90mm |
| Overall Length (Decimal Inch) | 4.831" |
| Overall Length (mm) | 122.70mm |
| Data Chip Provision | 1 |
| Product Type | Shell Mill Holder |
