Product Specifications
| Manufacturer Part Number | 02578590 |
| Maximum Work Piece Parting Diameter (Decimal Inch) | 5.512" |
| Maximum Work Piece Parting Diameter (mm) | 140.00mm |
| Maximum Cutting Depth (Decimal Inch) | 2.756" |
| Maximum Cutting Depth (mm) | 70.00mm |
| Cutting Width (Decimal Inch) | 0.158" |
| Cutting Width (mm) | 4.00mm |
| Functional Height (Decimal Inch) | 0.984" |
| Functional Height (mm) | 25.00mm |
| Overall Length (Decimal Inch) | 5.906" |
| Overall Length (mm) | 150.00mm |
| Overall Width (Decimal Inch) | 0.134" |
| Overall Width (mm) | 3.40mm |
| Cutting Direction | Neutral |
| Tool Cutting Edge Angle (Degree) | 90 Degree |
| Shank Type | Blade |
| Version (Internal/External/Both) | External |
| Product Type | Indexable Cutoff Blade |
