Product Specifications
| Manufacturer Part Number | 02573304 |
| Inscribed Circle Diameter (Decimal Inch) | 0.500" |
| Inscribed Circle Diameter (mm) | 12.70mm |
| Cutting Edge Effective Length (Decimal Inch) | 0.150" |
| Cutting Edge Effective Length (mm) | 3.81mm |
| Shank Width (mm) | 19.00mm |
| Functional Width (mm) | 11.78mm |
| Corner Radius (Decimal Inch) | 0.047" |
| Corner Radius (mm) | 1.20mm |
| Insert Thickness (Decimal Inch) | 0.125" |
| Insert Thickness (mm) | 3.18mm |
| Cutting Edge Condition Code | E |
| Cutting Edge Count | 8 |
| Pocket Seat Code of The Cutter | SN..1203 |
| Insert Size And Shape | SNEX1203 |
| Insert Included Angle (Degree) | 90 Degree |
| Material | PCBN |
| Product Type | Milling Insert |
