Product Specifications
| Manufacturer Part Number | 02573289 |
| Inscribed Circle Diameter (Decimal Inch) | 0.375" |
| Inscribed Circle Diameter (mm) | 9.52mm |
| Wiper Edge Length (Decimal Inch) | 0.035" |
| Wiper Edge Length (mm) | 0.90mm |
| Cutting Edge Effective Length (Decimal Inch) | 0.113" |
| Cutting Edge Effective Length (mm) | 2.86mm |
| Shank Width (mm) | 31.00mm |
| Functional Width (mm) | 19.80mm |
| Corner Radius (Decimal Inch) | 0.032" |
| Corner Radius (mm) | 0.80mm |
| Insert Thickness (Decimal Inch) | 0.125" |
| Insert Thickness (mm) | 3.18mm |
| Cutting Edge Condition Code | E |
| Cutting Edge Count | 8 |
| Pocket Seat Code of The Cutter | SN..0903 |
| Insert Size And Shape | SNEN0903 |
| Insert Included Angle (Degree) | 90 Degree |
| Material | PCBN |
| Product Type | Milling Insert |
