Product Specifications
| Manufacturer Part Number | 02465994 |
| Functional Length (Decimal Inch) | 0.130" |
| Functional Length (mm) | 3.30mm |
| Insert Length (Decimal Inch) | 0.306" |
| Insert Length (mm) | 7.78mm |
| Cutting Width (Decimal Inch) | 0.079" |
| Cutting Width (mm) | 2.00mm |
| Maximum Cutting Depth Insert (Decimal Inch) | 0.067" |
| Maximum Cutting Depth Insert (mm) | 1.70mm |
| Corner Radius (Decimal Inch) | 0.004" |
| Corner Radius (mm) | 0.10mm |
| Cutting Edge Count | 1 |
| Clearance Angle Major (Degree) | 7 Degree |
| Insert Hand | Left Hand |
| Insert Size And Shape | LCEX08 |
| Material | Carbide |
| Product Type | Grooving Insert |
