Product Specifications
| Manufacturer Part Number | 02427191 |
| Cutting Diameter (mm) | 83.46mm |
| Cutting Diameter (Decimal Inch) | 3.286" |
| Contact Surface Diameter Machine Side (Decimal Inch) | 3.543" |
| Contact Surface Diameter Machine Side (mm) | 90.00mm |
| Maximum Cutting Diameter (Decimal Inch) | 4.000" |
| Maximum Cutting Diameter (mm) | 101.60mm |
| Functional Length (Decimal Inch) | 2.000" |
| Functional Length (mm) | 50.80mm |
| Cutting Item Material Type | Steel |
| Maximum Ramping Angle (Degree) | 0.27 Degree |
| Programming Radius (Decimal Inch) | 0.138" |
| Programming Radius (mm) | 3.50mm |
| Maximum Rotational Speed (rpm) | 9100 rpm |
| Shank Type | Arbor |
| Insert Seat Size Code | 160 |
| Product Type | High Feed Trigon Shape Insert |
