Product Specifications
| Manufacturer Part Number | 02205497 |
| Corner Radius (Decimal Inch) | 0.032" |
| Corner Radius (mm) | 0.80mm |
| Theoretical Cutting Edge Length (Decimal Inch) | 0.394" |
| Theoretical Cutting Edge Length (mm) | 10.00mm |
| Insert Thickness (Decimal Inch) | 0.213" |
| Insert Thickness (mm) | 5.40mm |
| Cutting Edge Count | 4 |
| Cutting Geometry Type Technical | M10 |
| Insert Rake Angle (Degree) | 10 Degree |
| Material | Carbide |
| Insert Hand | Neutral |
| Product Type | Disc Milling Insert |
