Product Specifications
| Manufacturer Part Number | 00075843 |
| Inscribed Circle Diameter (Decimal Inch) | 0.500" |
| Inscribed Circle Diameter (mm) | 12.70mm |
| Corner Radius (Decimal Inch) | 0.038" |
| Corner Radius (mm) | 0.97mm |
| Insert Thickness (Decimal Inch) | 0.185" |
| Insert Thickness (mm) | 4.71mm |
| Thread Form Type | API - External Threading |
| API Code | V038R |
| Cutting Edge Count | 3 |
| Insert Hand | Right Hand |
| Tooth Count | 1 |
| Profile Included Angle (Degree) | 60 Degree |
| Material | Carbide |
| Product Type | Laydown Threading Insert |
