Product Specifications
| Manufacturer Part Number | 00072332 |
| Minimum Cutting Diameter Internal (Decimal Inch) | 0.600" |
| Minimum Cutting Diameter Internal (mm) | 15.24mm |
| Connection Diameter Machine Side (Decimal Inch) | 0.625" |
| Connection Diameter Machine Side (mm) | 15.88mm |
| Shank Diameter (Decimal Inch) | 0.625" |
| Shank Diameter (mm) | 15.88mm |
| Usable Length (Decimal Inch) | 1.250" |
| Usable Length (mm) | 31.75mm |
| Functional Length (Decimal Inch) | 5.500" |
| Functional Length (mm) | 139.70mm |
| Height of Tool Holder Shank (Decimal Inch) | 0.441" |
| Height of Tool Holder Shank (mm) | 11.20mm |
| Shank Type | Cylindrical |
| Cutting Direction | Right Hand |
| Insert Clamping System | S |
| Product Type | Indexable Threading Toolholder |
