Product Specifications
| Manufacturer Part Number | 00070081 |
| Cutting Diameter (Decimal Inch) | 1.000" |
| Cutting Diameter (mm) | 25.40mm |
| Connection Diameter Machine Side (Decimal Inch) | 1.000" |
| Connection Diameter Machine Side (mm) | 25.40mm |
| Maximum Cutting Diameter (Decimal Inch) | 1.551" |
| Maximum Cutting Diameter (mm) | 39.40mm |
| Shank Diameter (Decimal Inch) | 1.000" |
| Shank Diameter (mm) | 25.40mm |
| Protruding Length (Decimal Inch) | 2.913" |
| Protruding Length (mm) | 74.00mm |
| Shank Length (Decimal Inch) | 3.543" |
| Shank Length (mm) | 90.00mm |
| Overall Length (Decimal Inch) | 5.118" |
| Overall Length (mm) | 130.00mm |
| Maximum Depth of Cut (mm) | 7.00mm |
| Maximum Depth of Cut (Decimal Inch) | 0.276" |
| Tool Cutting Edge Angle (Degree) | 45 Degree |
| Tool Cutting Edge Angle In Feed Direction End (Degree) | 90 Degree |
| Tool Cutting Edge Angle In Feed Direction Side (Degree) | 45 Degree |
| Number of Flute | 2 |
| Maximum Rotational Speed (rpm) | 16900 rpm |
| Shank Type | Weldon |
| Product Type | Indexable Square-Shoulder End Mill |
