Product Specifications
| Manufacturer Part Number | 00030484 |
| Fixing Hole Diameter (mm) | 6.90mm |
| Inscribed Circle Diameter (mm) | 19.85mm |
| Insert Length (mm) | 47.83mm |
| Corner Radius (mm) | 25.00mm |
| Insert Thickness (mm) | 10.16mm |
| Cutting Edge Count | 2 |
| Clearance Angle Major (Degree) | 15 Degree |
| Insert Rake Angle (Degree) | -2 Degree |
| Insert Hand | Right Hand |
| Cutting Geometry Type | M |
| Cutting Geometry Type Technical | M14 |
| Pocket Seat Code of The Cutter | 218.20-250 |
| Insert Size And Shape | 218.20-250 |
| Insert Shape Code | 218.20 |
| Material | Carbide |
| Product Type | Milling Insert |
