Product Specifications
| Manufacturer Part Number | 00024926 |
| Fixing Hole Diameter (Decimal Inch) | 0.154" |
| Fixing Hole Diameter (mm) | 3.90mm |
| Inscribed Circle Diameter (Decimal Inch) | 0.472" |
| Inscribed Circle Diameter (mm) | 12.00mm |
| Insert Diameter (Decimal Inch) | 0.472" |
| Insert Diameter (mm) | 12.00mm |
| Corner Radius (Decimal Inch) | 0.236" |
| Corner Radius (mm) | 6.00mm |
| Insert Thickness (Decimal Inch) | 0.156" |
| Insert Thickness (mm) | 3.97mm |
| Cutting Edge Count | 4 |
| Clearance Angle Major (Degree) | 15 Degree |
| Insert Hand | Neutral |
| Cutting Geometry Type | MD |
| Cutting Geometry Type Technical | MD09 |
| Pocket Seat Code of The Cutter | RDMW12T3 |
| Insert Size And Shape | RDMW12T3 |
| Insert Shape Code | R |
| Material | Carbide |
| Product Type | Milling Insert |
