Product Specifications
| Manufacturer Part Number | 00009150 |
| Fixing Hole Diameter (Decimal Inch) | 0.165" |
| Fixing Hole Diameter (mm) | 4.19mm |
| Inscribed Circle Diameter (Decimal Inch) | 0.375" |
| Inscribed Circle Diameter (mm) | 9.52mm |
| Cutting Edge Effective Length (Decimal Inch) | 0.598" |
| Cutting Edge Effective Length (mm) | 15.20mm |
| Theoretical Cutting Edge Length (Decimal Inch) | 0.650" |
| Theoretical Cutting Edge Length (mm) | 16.50mm |
| Corner Radius (Decimal Inch) | 0.032" |
| Corner Radius (mm) | 0.80mm |
| Insert Thickness (Decimal Inch) | 0.125" |
| Insert Thickness (mm) | 3.18mm |
| Cutting Edge Count | 3 |
| Clearance Angle Major (Degree) | 11 Degree |
| Insert Included Angle (Degree) | 60 Degree |
| Insert Hand | Neutral |
| Insert Size And Shape | TP1606 |
| Insert Shape Code | T |
| Material | Carbide |
| Product Type | Turning Insert |
