Product Specifications
| Coating | Uncoated |
| Corner Radius (Inch) | 1/64" |
| Corner Radius (Decimal Inch) | 0.015" |
| Angle per Side | 30 Degree |
| Included Angle | 60 Degree |
| Insert Height (Decimal Inch) | 0.5480" |
| Insert Hole Diameter (Inch) | 1/8" |
| Insert Hole Diameter (Decimal Inch) | 0.125" |
| Insert Inscribed Circle (Inch) | 3/8" |
| Insert Inscribed Circle (Decimal Inch) | 0.375" |
| Insert Style | TD |
| Insert Thickness (Inch) | 1/8" |
| Insert Thickness (Decimal Inch) | 0.125" |
| Screw Thread | 4-40 |
