Features:
- Variable rake geometry alters and controls the cutting dynamic taking chatter suppression to an unprecedented level
- Unequal helix design changes the cutting angle to improve harmonics
- Unequal flute spacing helps to disrupt the rhythmic pattern created by the cutting edge helping to suppress damaging harmonics
- Enhanced corner geometry with tight tolerance corner radius
- Recommended for materials ≤ 45 HRC (≤ 420 BHN)
Product Specifications
| Cutting Diameter (mm) | 16.0mm |
| Shank Diameter (mm) | 16.0mm |
| Length of Cut (mm) | 20.0mm |
| Overall Length (mm) | 115mm |
| Shank Length (mm) | 50.0mm |
| Cut of Direction | RHC |
| Flute Type | Spiral |
| Reach (mm) | 65mm |
| Corner Radius (mm) | 4.1 mm |
| Helix Angle | 35-38 Degree |
| Coating | TX |
| Number of Flutes | 4 |
