Features:
- Two flute design is ideal for softer alloyed, non-ferrous material applications that require slotting or involve heavy chip loads
- Proprietary coating allows for superior chip flow, driving industry leading productivity and value, even at low spindle speeds
- High performance carbide substrate designed specifically for Micro Tool applications
- Broad portfolio, offering consistent lengths of cut, to ensure application demands are met
- Advanced geometries that extend tool life, reduce chatter, cut cycle times, and improve part quality
- All micro tools are manufactured in accordance with the KSPT ISO certified quality procedures
Product Specifications
| Cutting Diameter (mm) | 0.7mm |
| Shank Diameter (mm) | 3.0mm |
| Length of Cut (mm) | 1.0mm |
| Overall Length (mm) | 38.0mm |
| Shank Length (mm) | 37.0mm |
| Cut of Direction | RHC |
| Flute Type | Spiral |
| Cleared Length (mm) | 1.1 mm |
| Helix Angle | 30 Degree |
| Coating | AlTiN |
| Number of Flutes | 2 |
