The specially engineered end profile of these High Feed End Mills for Aluminum and Non-Ferrous Materials reduces cutting forces, while its reduced neck geometry provides maximum strength in long reach and deep pocketing applications.
Features:- Designed for outstanding performance and maximum feed rates in aluminum and non-ferrous materials
- Specifically engineered end profile for optimal tool engagement and reduced cutting forces
- Reduced neck provides maximum strength in long reach and deep pocketing applications
- End cutting geometry (non-center cutting)
- h6 shank tolerance for high precision tool holders
- Zplus coating offers higher hardness and added lubricity for maximum performance
- Solid carbide
- CNC ground in the USA
Product Specifications
| Tool Number | 86420 |
| Cutter Diameter (Inch) | 0.5000" |
| Length of Cut (Inch) | 1.6250" |
| Overall Length (Inch) | 4.0000" |
| Theoretical Radius (Inch) | 0.0628" |
| No of Flutes | 4 |
| LOC Multiple | 3.2x |
| Shank Diameter (Inch) | 0.5000" |
| Shank Length (Inch) | 2.3750" |
| Coating | Tplus |
