Achieve massive cycle time reduction and vastly improved surface finish with this fully stocked Helical Solutions selection of Multi Axis Finishers, which feature End Mills with a taper form with three tangential radii.
- Specially defined profile for massive reductions in cycle time and vastly improved surface finish
- Taper form with three tangential radii and offered in a variety of angles for maximum performance and optimal clearance angle for any workpiece
- 6 flute geometry specifically designed for finishing in stainless steel, high temperature alloys, and other ferrous materials
- Center cutting
- Tplus coating offers high hardness for improved tool life and increased edge strength in difficult-to-machine materials
- Solid carbide
- CNC ground in the USA
Product Specifications
| Cutter Diameter (Inch) | 0.7500" (3/4) |
| Length of Cut (Inch) | 0.6562" (21/32) |
| Overall Length (Inch) | 4" |
| Corner Radius (Inch) | 0.3750" (3/8) |
| Included Angle | 60 |
| No of Flutes | 6 |
| Shank Diameter (Inch) | 0.7500" (3/4) |
| Finish/Coating | TPLUS |
| Center Cutting (Yes/No) | Yes |
