Product Specifications
| Head Diameter (Decimal Inch) | 0.0800" |
| Neck Diameter (Inch) | 3/64" |
| Neck Diameter (Decimal Inch) | 0.0470" |
| Length of Cut (Decimal Inch) | 0.0140" |
| Neck Length (Decimal Inch) | 0.0700" |
| Overall Length (Inch) | 1-1/2" |
| Overall Length (Decimal Inch) | 1.5000" |
| Angle per Side | 45 Degree |
| Included Angle | 90 Degree |
| Number of Flutes | 4 |
| Reach Multiple | 1.5x |
| Shank Diameter (Inch) | 1/8" |
| Shank Diameter (Decimal Inch) | 0.1250" |
| Metric (Yes/No) | No |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Finish/Coating | AlTiN |
| Double Ended (Yes/No) | No |
| Weldon Flat (Yes/No) | No |
| Coolant Through (Yes/No) | No |
