Product Specifications
| Cutter Diameter (Inch) | 5/16" |
| Cutter Diameter (Decimal Inch) | 0.3125" |
| Length of Cut (Inch) | 13/16" |
| Length of Cut (Decimal Inch) | 0.8120" |
| Overall Length (Inch) | 2-1/2" |
| Overall Length (Decimal Inch) | 2.5000" |
| Angle per Side | 30 Degree |
| Included Angle | 60 Degree |
| Number of Flutes | 4 |
| LOC Multiple | 3x |
| Web Thickness | 0.0100" |
| Shank Diameter (Inch) | 5/16" |
| Shank Diameter (Decimal Inch) | 0.3125" |
| Metric (Yes/No) | No |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Finish/Coating | AlTiN Nano |
| Double Ended (Yes/No) | No |
| Weldon Flat (Yes/No) | No |
| Coolant Through (Yes/No) | No |
