Features
- Ideal for back chamfering, chamfering, deburring, and milling a "V-groove"
- Reduced straight shank allows any chucking depth
- Tip of included angle ground to a point
- 60 Degree angle can also be used for thread milling
- Solid carbide head brazed onto steel shank
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | 877572 |
| Cutter Diameter (Inch) | 0.3125" (5/16) |
| Shank Diameter (mm) | 4mm |
| Cutter Width (Inch) | 0.1550" |
| Overall Length (Inch) | 3.1550" |
| Shank Diameter (Inch) | 0.1575" |
| Angle per Side | 45 Degree |
| Included Angle | 90 Degree |
| Number of Flutes | 8 |
| Coating | Uncoated |
| Profile | Pointed |
